Then I could finally cut the groove for the playfield TV into the case (a router is really a great tool) and stabilize the whole thing afterwards with the wall mount screws. I left 15 mm distance from the glass pane for the playing field, so that the air can circulate a little bit there. With the help of a ‚hole cutter‘ I was able to cut the 28 mm holes for the additional pinball buttons and the 4 navigation buttons into the related plates.
For the monitor mount, I adapted an angle profile and covered it with good fabric tape to prevent scratches on the monitor housing. However, the buttons (on/off etc.) are still at the bottom and protrude a little… but they are now perfectly recessed in the groove. In the V2 I used the PROLITE X4071UHSU-B1 (4K), which fitted in incl. My pinball case has 52 cm, the TV still had about 52.6 cm „stripped“ (I left the frame at the front to „centre the front“), so the plan was to cut a groove 0.5 cm deep on each side. In my V1, I had chosen the (FullHD) Samsung UE40J6250 TV for my „playfield screen“. Then I removed all the metal parts and rust (rust film) in a nice Cola bath (but without Jack Daniels) and polished or sanded them.
#Pindmdv3 for pro pinball ultra Pc
and also various hardware stores… the first steps were roughly clear.įirst of all I removed all strips and woods from the inside of the cabinet, made a hole and also a reinforcement for the subwoofer and a hole for the inspection door on the back (to get easy access to the PC later). The first thing I bought concerning virtual pinball was a (not virtual) old pinball case (PinBall Champ82) including coin slot, disc & siderails.Īfter I spent a lot of my (analog) spare time in digital boards/forums, blogs, YouTube & Co.
Kassentüre nach dem lackieren und zusammenbauen / Coin door ready.28 mm Löcher mit Lochschneider / 28 mm holes with hole cutter tool.Stromanschluss unten / Power connection (bottom).Ventliator (Flippergehäuse) eingelassen / Fan mounted flat in Cabinet case.Belüftung des Netzteils (unten) / Cooling of power supply (bottom).VPIN Case mit Computer / VPIN case with computer.Playfield TV eingelassen in gefräßte Nut / Playfield TV mounted in notch.Sound Verstärkung / strengthen Subwoofer.Edelstal Blenden im Cola-bad / Stainless steel stuff take a coke-bath 🙂.20x Leds 5 volts (red, white, blue) | Ebay 18 €.6x Arcade button red (5V LED) | Ebay 17 €.4x Illuminated pushbutton, 44 mm, blue, white & red | Arcadeshop 13 €.4x Illuminated pushbutton ES, 34 mm, white | Arcadeshop 15 €.2x Halo Button, 50.5 mm, red & blue | Arcadeshop 12 €.Various Terminal blocks 4, 5, 10 and 12 | Amazon ~ 28 €.Vehicle management set 2,50 mm²| Amazon 20 €.Elektronic cable set 0,32mm² | Amazon 20 €.JST-SM plugs & Sockets (4 pol.) | Amazon 8 €.JST-SM plugs & Sockets (3 pol.) | Amazon 16 €.Dupont- Plug-Set & Crimp-tool | Amazon 27 €.140 mm PWM PST fan (cooling of microcontroller) | Amazon 10 €.140 mm PWM PST fan (power supply cooling) | Amazon 10 €.Power outlet strip 4-Fach | Amazon 12 €.LED-Power supply unit 102W 12V 8,5A | Amazon 28 €.
